The ECCLQ is designed to provide strong column-beam connections in end-of-beam applications when two beams intersect in an “L” formation on top of a column. When properly installed, this column cap helps to distribute the load from the beams and provides support for the connection.
The ECCLQ uses Strong-Drive SDS Heavy-Duty Connector screws (included) to provide faster installation and a lower profile than standard through bolts.

• Model No. ECCLRQ444HDG
• L-Shape End Column Cap for 4x Beam, 4x Post w/ SDS Screws
• Direction. Skewed Right
• Fasteners included. 1/4″ x 2-1/2″ Strong-Drive SDS Heavy-Duty Connector screws
• Material. Steel
• Finish. Hot Dip Galvanized
• Product Guide & SPECS : View Specifications

Key Features

• Screws are configured to provide high uplift design values
• Certified welds for confidence in strength and loading
• Diamond holes to provide temporary fastening

Installation

• Install 1/4″ x 2 1/2″ Strong-Drive SDS Heavy-Duty Connector screws, which are provided, in all round holes. (Lag screws will not achieve the same load.)
• No additional welding is allowed.

Options

• Contact us for Configurable Options and Special orders
• Many combinations of beam and post sizes can be manufactured (refer to worksheet Options for Multiple-Beam Column Caps).
• Available in widths up to 8″ wide.
• ECCLQ is available in left or right side beam orientations. Specify ECCLLQ or ECCLRQ.
• Straps may be rotated.
• Column caps may be ordered without the column straps for field welding to a steel column, full loads apply for the beam and the post cap. Specify “No Straps” when ordering. Weld by designer. These models have no coating.

This is a Special Order item, or Made to Order by Simpson Strong-Tie, it is non-refundable. Please verify that all configurations / specifications are correct before checking out.

Note: Product dimensions and/or Screw or Bolt holes may differ from picture. Please see item description for specifications.
